Suspension installation Ceiling installation Direct light emission Energy rating Compliant with the directive for electromagnetic compatibility 89/336 / EEC; 73/23 / EEC Insulation class I Flammable surfaces suitable for installation
Chromatic rendered index ≥80 Chromatic rendered index ≥90 Color tolerance - 3 Lifetime: 80000 hours Photobiological risk Degree of protection IP40
Mountings:
• Surface mounted fitting, by acc. 7516
• Suspended fitting, by acc. 7516; 417SP-2
• Presetting for continuous line mounting
Light emission:
Direct
Symmetric
Body:
In shockproof polycarbonate, self-extinguishing V2, opal, produced by extrusion
Optical device:
Diffuser in opal polycarbonate
Light source:
• LED CRI ≥80 Ra
• 3000K
• 4000K
• Color tolerance 3 MacAdam (3 SDCM)
Wiring:
Class I
Feeding 220~240 V / 50-60 Hz
Performance data:
• Efficiency A+
• Protection level IP65
• Lifetime (Ta=25°C) 50000h L80B10
Marks:
CE
Regulations:
EN 60598-1
EN 60598-2-1
EN 62031
Photobiological safety of lamps and lamp system:
EN 62471
IEC/TR 62778
Exempt risk – GR 0
Directives:
2014/35/UE
2014/30/UE
VERSIONS ON REQUEST (if possible)
• Dimmable electronic ballast 1-10V
• DALI dimmable electronic ballast
• Ra 90

Download

Eulumdat: 7512 OP

Eulumdat: 7512 OP

Download (117.67k)

ds_7512_TUBOLUCE-70_OP

Data Sheet: TUBOLUCE 70 - 7512 OP

Download (716.61k)
